TECHNICAL FEATURES
Detection properties
| Nominal sensing distance | 60m | |
| Sensitivity adjustment | Trimmer | |
Application
| Function Principle | Through beam receiver | |
| Description | Large case vertical mount | |
| Optic position | Radial 90° | |
| Functions | Through beam receiver | |
Outputs
| Output type | NPN/PNP – Dark/Light sel. | |
| Switching frequency | 500Hz | |
| Response time | 1 | |
Electrical data
| Operating Voltage | 12…30VDC | |
| No-Load supply current | ≤ 25mA | |
| Load current | ≤100mA | |
| Output voltage drop | ≤ 2,4V | |
| LED indicators | Yellow (output state) Green (stability) | |
| Short-circuit protection | YES | |
| Reverse Polarity Protection | Yes | |
| Emission | n/a | |
| Interference to external light | according to EN 60947-5-2 : 2020 | |
| Impulsive Overvoltage Protection | Yes | |
| Insulation resistance | >20 MΩ 500 Vdc, between electronics and housing | |
| Contact resistance | 500 Vac 1 min., between electronics and housing | |
Mechanical data
| Dimensions | 25x85x70 | |
| Housing Material | PBT Fiber Glass reinforced | |
| Connections | M12 plug | |
| Active Head Material | PMMA | |
| Storage temperature | – 40°C…+70°C | |
| Material | Plastic – PBT / PC | |
| Diameter/Dimension | Cubic | |
Test/Approvals
| Approvals | CE cULus | |
| Shocks and vibrations | 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6) | |
Generical Data
| Dimensions | 25x85x70 | |
| Operating Temperature | – 40°C…+ 55°C | |
| Mechanical Protection | IP67 | |
